DS-2CE56D8T-IT3E

Camera
Image Sensor: | 2.0 megapixel progressive scan CMOS
Signal System: | PAL/NTSC
Frame Rate: | PAL: 1080p@25fps
                       NTSC: 1080p@30fps
Resolution: | 1920 (H) × 1080 (V)
Min. illumination: | Color: 0.005 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Time: | PAL: 1/25 s to 1/50, 000 s
                         NTSC: 1/30 s to 1/50, 000 s
Slow Shutter: | Max.: 16 times
Lens: | 2.8 mm fixed focal lens
Horizontal Field of View: | 103.5°
Lens Mount: | M12
Day & Night: | IR cut filter
Angle Adjustment: | Pan: 0°to 360°, Tilt:0°to 75°, Rotate: 0°to 360°
Synchronization: | Internal synchronization
WDR (Wide Dynamic Range): | > 120 dB
Menu
AGC: | Support
Day/Night Mode: | Auto/Color/BW (Black and White)
White Balance: | ATW/MANUAL
Privacy Mask: | ON/OFF, 4 programmable privacy masks
Motion Detection: | 4 programmable motion areas
Backlight Compensation: | WDR/BLC/HLC/OFF
3D DNR (Digital Noise Reduction): | On
Language: | English, Chinese
Functions: | Brightness, Sharpness, Mirror, Smart IR
Interface
Video Output: | 1 HD analog output
General
Operating Conditions: | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Power Supply: | 12 VDC±25%/PoC.af
Power Consumption: | Max. 4 W
Ingress Protection: | IP67
Material: | Metal
IR Range: | Up to 40 m
Communication: | Up the coax, Protocol: HIKVISION-C (TVI output)
Dimensions: | Φ 110 mm × 93.2 mm (Φ 4.33" × 3.67")
Weight: | 350 g (0.77 lb.)

Nota: Alimentador não incluído.
