Câmara IP 2Mpx DarkFighter, 1080p, lente 4.8~120mm, zoom ótico 25x, zoom digital 16x, alarme 7E/2S, áudio 1E/1S, cartão MicroSD/SDHC/SDXC, AC24V/Hi-PoE, IP66

● 1/2.8" progressive scan CMOS
● Up to 1920 × 1080 resolution
● Min. illumination: Color: 0.002 Lux @(F1.2, AGC ON)
                               B/W: 0.0002 Lux @(F1.2, AGC ON)
● 25 × optical zoom, 16 × digital zoom
● 120dB WDR, 3D DNR, HLC
● 24 VAC &Hi-PoE
● Support H.265+/H.265 video compression
● Deep-learning-based target classification algorithm for auto-tracking 2.0 and perimeter protection
● IK10, IP66


Image Sensor:| 1/2.8" progressive scan CMOS
Min. Illumination:| Color: 0.05 Lux @(F1.6, AGC ON) B/W: 0.01 Lux @(F1.6, AGC ON)
Shutter Time:| 1/1 s to 1/30,000 s
White Balance:| Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
AGC:| Auto/Manual
Day & Night:| IR cut filter
Digital Zoom:| 16×
Privacy Mask:| 24 programmable privacy masks
Focus Mode:| Auto/Semi-automatic/Manual
3D DNR:| Support
BLC:| Support
HLC:| Support
WDR:| 120dB
Defog:| Support
EIS:| Support
Regional Exposure:| Support
Regional Focus:| Support
Focal Length:| 4.8 mm to 120 mm, 25× Optical
Zoom Speed:| Approx. 3.7 s (optical lens, wide-tele)
Field of View:| Horizontal field of view: 61.4° to 2.7° (wide-tele)
                        Vertical field of view: 40.7° to 1.7° (wide-tele)
                        Diagonal field of view: 70.0° to 3.2° (wide-tele)
Working Distance:| 10 mm to 1500 mm (wide-tele)
Aperture Range:| F1.6 to F4.0
Movement Range (Pan):| 360° endless
Pan Speed:| Configurable, from 0.1°/s to 300°/s, Preset Speed: 540°/s
Movement Range (Tilt):| From -5° to 90°
Tilt Speed:| Configurable, from 0.1°/s to 240°/s, Preset Speed: 400°/s
Proportional Zoom:| Support
Presets:| 300
Patrol Scan:| 8 patrols, up to 32 presets for each patrol
Pattern Scan:| 4 pattern scans, record time over 10 minutes for each scan
Power-off Memory:| Support
Park Action:| Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
PTZ Status Display:| Support
Preset Freezing:| Support
Scheduled Task:| Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome
                            Reboot/Dome Adjust/Aux Output
Smart Features
Smart Detection:| Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Face
                             Detection, Audio Exception Detection
Smart Tracking:| Manual Tracking, Auto Tracking, Event Tracking
Smart Record:| ANR (Automatic Network Replenishment), Dual-VCA
Max. Resolution:| 1920×1080
Main Stream:| 50Hz: 25fps(1920×1080, 1280×960, 1280×720)
                                  50fps(1920×1080, 1280×960, 1280×720)
                        60Hz: 30fps(1920×1080, 1280×960, 1280×720)
                                   60fps(1920×1080, 1280×960, 1280×720)
Sub-Stream:| 50Hz: 25fps(704×576, 640×480, 352×288)
                      60Hz: 30fps(704×480, 640×480, 352×240)
Third Stream:| 50Hz: 25fps(1920×1080, 1280×960, 1280×720, 704×576, 640×480, 352×288)
                        60Hz: 30fps(1920×1080, 1280×960, 1280×720, 704×480, 640×480, 352×240)
ROI:| Support
SVC:| Support
Video Compression:| Main Stream: H.265+/H.265/H.264+/H.264
                                  Sub-Stream: H.265/H.264/MJPEG
                                  Third Stream: H.265/H.264/MJPEG
                                   H.264 with Baseline/Main/High Profile
Audio compression:| G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Protocols:| IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP,
                  DHCP, PPPoE, Bonjour
Simultaneous Live View:| Up to 20 channels
User/Host:| Up to 32 users
                   3 levels: Administrator, Operator and User
Security Measures:| User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x
                                 port-based network access control; IP address filtering
System Integration
Alarm Input:| 7-ch alarm input
Alarm Output:| 2-ch alarm output
Alarm Linkage:| Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording,
                          Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
Audio Input:| 1-ch audio input
Audio Output:| 1-ch audio output
Network Interface:| 1 RJ45 10 M/100 M Ethernet Interface; Hi-PoE
CVBS:| Support
RS-485:| HIKVISION, Pelco-P, Pelco-D, self-adaptive
Storage:| Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR
API:| Open-ended, support ONVIF, and CGI, support HIKVISION SDK and Third-Party Management Platform
Client:| iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser:| IE7+, Chrome18-42, Firefox5.0+, Safari5.02+
Power:| 24 VAC (Max. 60 W) Hi-PoE (Max. 50 W)
Working Temperature:| -40°C to 65°C (-40°F to 149°F)
Working Humidity:| ≤ 90% Protection Level IP66 Standard, TVS 6,000V Lightning Protection, Surge Protection and Voltage Transient Protection
Dimensions:| Φ 220 mm × 302 mm (Φ 8.66" × 11.89")
Weight:| Approx. 4 kg (8.82 lb)


Nota: Alimentador não incluído.
