UT195DS

UT195DS

126,58 €
136,11 €
True RMS industrial digital multimeter - IP65 and 2 m drop proof - DC and AC measurement up to 1000V / 20A - Integrated flashlight - Resistance, Capacitance and Frequency Measurement - Buzzer for continuity test
Description
  • UNI-T
  • Industrial digital multimeter
  • IP65 and 2 m drop proof CAT III 1000V/ CAT IV 600V
  • LCD backlight display up to 6000 accounts
  • DC and AC voltage measurement up to 1000 V
  • DC and AC current measurement up to 20 A
  • High accuracy in AC with built-in True RMS function
  • Resistance, Capacitance and Frequency Measurement
  • Buzzer for continuity test
  • Diode test
  • Automatic shutdown
  • Integrated flashlight
Specifications
BrandUni-T
Measuring range DC and AC voltageDC 1000V ±(0.5%+3)
AC 750V ±(0.7%+3); Frequency of response: 45~5kHz
DC and AC current measuring rangeDC 20A ±(0.8%+3)
AC 20A ±(1%+3); Frequency of response: 45~5kHz
Resistance measuring range60MΩ ±(0.8%+2)
Capacitance measuring range60mF ±(3%+5)
Frequency measurement range60Hz~40MHz ±(0.1%+4)
Duty Cycle Range0.1%~99.9% ±(2%+5)
Display accountsUp to 6000
Auto Range / Manual Range / True RMSYes, it has
Relative modeYes, it is available
Continuity testYes, it is available
Diode testYes, it is available
Three-phase motor sequence testYes, it is available
Power2 x batteries (LR6) 1.5V
Dimensions195 (H) x 95 (W) x 58 (D) mm
Weight484 g
SecurityCAT III 1000V/ CAT IV 600V CAT IV [%VAR%]
Contents
  • Digital multimeter
  • Test leads
  • Temperature probe
  • Batteries
  • User instructions
