UV-IPC2225SE-DF40K-WL-I0

UV-IPC2225SE-DF40K-WL-I0

5 MP IP Camera - Prime range - 1/2.7" Progressive Scan CMOS - 4.0 mm Lens - White light LEDs - Range 30 m - WEB, CMS, Smartphone and NVR interface
Description

Uniview

Bullet IP camera

Prime range

1/2.7" Progressive Scan CMOS

5 Megapixel 16:9 (2880x1620)

4 mm Lens

White light LEDs for color image 24/7

Range 30 m

WDR 120dB

Intelligent Perimeter Protection | Accurate detection of humans and vehicles (avoids false alarms)

Compression Ultra265/H.265/H.264

Audio

Alarms

PoE IEEE802.3af

Weatherproof IP67

Vandal proof IK10

Surge protection

MicroSD slot

WEB, CMS, Smartphone and NVR interface

ONVIF Compatible

Specifications
Brand Uniview
Range Prime
Image sensor 1/2.7" Progressive Scan CMOS
Maximum resolution 5 Megapixel (2880x1620)
Main Stream rate 25 fps (2880 x 1620, 2560 x 1440, 2304 x 1296) 30 fps (1920 x 1080)
Extra Stream rate 2º: 720p (1 ~ 30 FPS), 3º: D1 (1 ~ 25 FPS)
Compression Ultra265/H.265/H.264
Lens 4 mm
Minimum illumination 0.001 Lux (Colour)
Infrared range 30 m
Image improvements WDR 120dB, BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR
SIP (Smart Intrusion Prevention) Intelligent Intrusion Prevention. Accurate detection of humans and vehicles to avoid false alarms. Event due to line crossing, area intrusion or entry or exit of a previously defined area
Day / Night Automatic and configurable
Internal memory Slot for microSD card up to 256GB
Alarms 1 input / 1 relay
Audio 1 IN / 1 OUT
Network interface Ethernet 10/100 BaseT
Remote access Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
Interoperability ONVIF
Power DC 12 V / 9 W, PoE IEEE802.3af
Temp. operation -30º C ~ 60º C
Degree of protection Waterproof IP67, Vandal-proof IK10, Surge protection
Dimensions 85 (H) x 64 (W) x 246 (D) mm
Weight 920 g
Contents

Uniview IP Camera

Installation material

User instructions
