Contents
Uniview IP Camera
Installation tools
User instructions
Uniview
Turret IP Camera
Easy range
1/2.7" Progressive Scan CMOS
5 Megapixel (2880x1620)
2.8 mm Lens
0 Lux
IR Range 30 m
WDR 120dB
Compression Ultra265/H.265/H.264
Integrated microphone
RJ-45 10/100 BaseT
PoE IEEE802.3af
Weatherproof IP67
Surge protection
MicroSD slot
WEB, CMS, Smartphone and NVR interface
ONVIF Compatible
Brand | Uniview |
Range | Prime |
Image sensor | 1/2.7” Progressive Scan CMOS |
Image resolution | 5 Megapixel (2880X1620) |
Main stream rate | Main Stream: 5MP (2880*1620), Max 25fps;4MP (2560*1440), Max 25fps; 3MP (2304*1296), Max 30fps; 1080P (1920*1080), Max 30fps; |
Extra stream rate | 720P (1280*720), Max 25fps |
Compression | Ultra 265, H.265, H.264, MJPEG |
Lens | 2.8 mm |
Minimum illumination | 0.003Lux ( F1.6, AGC ON) |
Infrared range | 30 m |
Image improvements | WDR (120dB), BLC, HLC, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR |
Day/Night | Mechanical ICR filter |
Internal memory | MicroSD card, Max 256 GB |
Video backup | ANR video recovery technology by installing a Micro SD card |
Audio | Integrated microphone |
Network interface | Ethernet 10/100 BaseT |
Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
Interoperability | ONVIF |
Power | DC 12 V / 6 W, PoE IEEE802.3af |
Operating Temp | -30º C ~ 60º C |
Degree of protection | Weatherproof IP67 |
Dimensions | Φ118 x 95mm |
Weight | 350 g |
Uniview IP Camera
Installation tools
User instructions
