UV-XVR-104G3

38,96 €
41,89 €
Video recorder 5n1 - Uniarch - 4 CH HDTVI / HDCVI / AHD / CVBS + 2 extra IP - Audio - Supports 1 hard disk
Description
  • Uniarch
  • DVR 5n1
  • 4 BNC video CH (IP-replaceable)
  • AHD, TVI, CVI, CVBS, CVBS
  • 48 Mbps bandwidth supported
  • Maximum IP resolution 4 Mpx
  • Maximum analog resolution 5 Mpx
  • Audio
  • HDMI and VGA output
  • RS485
  • 2 x USB 2.0
  • Mouse
  • Space for 1 HDD up to 8 TB
  • WEB, CMS, Smartphone and NVR interface
  • ONVIF Compatible
Specifications
BrandUniarch
Video formatHDTVI / HDCVI / AHD / CVBS / IP
Video inputs4CH BNC
Hybrid configurationUp to 6 IP Channels (4Mpx) replacing all the BNC channels
Video outputs1 HDMI Full HD, 1 VGA
Audio inputs1 Channel RCA
Audio outputs1 Channel RCA
Bidirectional audioReusing the audio input/output
Display resolution1920x1080@60Hz, 1920x1080@50Hz, 1600x1200@60Hz, 1280x1024@60Hz, 1280x720@60Hz, 1024x768@60Hz
Maximum IP recording resolution4 Mpx
Analog cameras supportedTVI / AHD: 5MP@20fps, 4MP@30fps,1080P@30fps, 720P@60fps

CVI: 5MP@20fps, 4MP@30fps, 1080P@30fps, 720P@30fps
Main Stream recording encoding5MPLite@12fps; 4MPLite@15fps; 1080P@15FPS; 720P@25FPS
Extra Stream recording encodingD1@12FPS; D1@15FPS; D1@25FPS
Recording methodManual, programmed, motion detection
Internal memory1 HDD SATA 3.5" of up to 8TB (not included)
External interface2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485
Remote accessWeb Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
PowerDC 12V / 8W
Dimensions / Weight260mm × 218mm × 47mm / 1.1 kg
Contents
  • 5 in 1 Uniview recorder
  • Mouse
  • Power adapter
