UV-XVR-108G3

UV-XVR-108G3

47,02 €
50,56 €
Video recorder 5n1 - Uniarch - 8 CH HDTVI / HDCVI / AHD / CVBS + 4 extra IP - Audio - Supports 1 hard disk
Brand
Uniarch
Availability
2-5 Days
Questions about this item
Buy
Description
  • Uniarch
  • DVR 5n1
  • 8 BNC video CH (IP-replaceable)
  • AHD, TVI, CVI, CVBS, CVBS
  • 40 Mbps bandwidth supported
  • Maximum IP resolution 4 Mpx
  • Maximum analog resolution 5 Mpx
  • Audio
  • HDMI and VGA output
  • RS485
  • 2 x USB 2.0
  • Mouse
  • Space for 1 HDD up to 6 TB
  • WEB, CMS, Smartphone and NVR interface
  • ONVIF Compatible
Specifications
BrandUniarch
Video formatHDTVI / HDCVI / AHD / CVBS / IP
Video inputs8CH BNC
Hybrid configurationUp to 8 IP Channels (4Mpx) replacing all the BNC channels
Video outputs1 HDMI Full HD, 1 VGA
Audio inputs1 Channel RCA
Audio outputs1 Channel RCA
Bidirectional audioReusing the audio input/output
Display resolution1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768
Maximum IP recording resolution4 Mpx
Analog cameras supportedTVI / AHD: 5MP@12FPS; 4MP@15FPS; 1080P@30FPS; 720P@30FPS

CVI: 4MP@15FPS;1080P@30FPS; 720P@30FPS
Main Stream recording encodingTVI/CVI/AHD: 5MPLite@6fps; 4MPLite@8fps; 2MPLite@15FPS; 2MP@8FPS; 720P@15FPS
Extra Stream recording encodingD1@6FPS; D1@8FPS; D1@15FPS;
Recording methodManual, programmed, motion detection
Internal memory1 HDD SATA 3.5" of up to 6TB (not included)
External interface2 x USB (Mouse and backup) / RJ45 10M/100M/1000M (Ethernet) / RS485
Remote accessWeb Browser, CMS Software (EZStation), Smartphone (EZView/EZLive)
PowerDC 12V / 8W
Dimensions / Weight46 (H) x 260 (W) x 243 (D) mm / 1 kg
Contents
  • 5 in 1 Uniview recorder
  • Mouse
  • Power adapter
